Mosquito Screens

Karthik Engineering are the authorized distributors in South India for PHIFER WIRE PRODUCTS INC. USA. The world's largest manufacturer of Fiberglass & Aluminium insect screens (mosquito Mesh). We are also the authorized institutional distributors for India. The mosquito mesh is available in Fiberglass, Aluminium, Stainless Steel, Bronze, Super Solar, Polyester TuffScreen, Pool & patio & Polyester PetScreen. The mesh is sold in the form of 100ft. length rolls of varying widths (3', 4', 5', 6', 7‘, 8’, 9’, 10’ & 11’) to a close knit dealer network throughout South India, Goa & Gujarat. We are also the authorized Institutional Distributors for entire India for PHIFER Inc., the world's largest manufacturer of insect screens.


PHIFER INSECT SCREEN ALSO GREENGUARD CERTIFIED.

Greenguard is an indoor air quality certification program for low emitting products and materials. Greenguard children & schools certification establishes extremely strict chemicals emissions standard to accomodate the spacial needs of children in education and day care facilities.

PHIFER INSECT SCREEN ALSO PROTECTED WITH MICROBAN.

Microban antimicrobial protection works continuously to inhabit the growth of the bacteria, mold and mildew that can cause stains,odours and product deterioration.


ALUMINIUM SCREEN:

Tough, precision-made Aluminium screen is woven to the world's most exacting specifications and quality standards. After weaving, a treated Aluminium screens is scientifically degreased and dip-weld coated. Every point where the strands cross is sealed with a deposit of high quality pigment. This process assures dimensional stability, adds strength, helps reduce glare gives a uniform finish with no streaks or oil spots and adds additional protection against corrosion.

FIBERGLASS INSECT SCREEN:

Phiferglass screening is constructed of vinyl coated Fiberglass yarn. Phiferglass is strong, long lasting and not easily damaged, which makes it virtually the "carefree screening ". Fiberglass is woven from permanent glass yarn, which has been coated with high protective vinyl to ensure lasting beauty, colour and flexibility. Phiferglass is non-combustible and will not rust, corrode or stain.

SEEVUE STAINLESS STEEL BLACK INSECT SCREEN

Phifer SeeVue is woven from stainless steel 304 grade, which not only improves visibility with its fine wire diameter, but also makes this product much stronger than standard insect screen. SeeVue is an improved visibility insect screen (iVis) designed to maximize an outward view, making it sharper and more brilliant. It allows superior airflow and meets the high standard of insect protection

PET SCREEN (PET RESISTANT INSECT SCREEN)

Phifer Pet resistant IS meets the needs of pet owners by resisting tear and punctures caused by Dogs & cats. Made of strong vinyl-coated polyester. Pet Screen is seven times stronger than traditional insect screening and offers excellent outward visibility. Ideal for those areas prime for potential damage and heavy wear in high traffic areas.

BETTER VUE INSECT SCREEN

Better Vue is Phifer's New iVis (Improved visibility Screening) product that allows you to "See the view not the screen ". This fabric also improves daytime privacy while offering good outward visibility.

SUPER SOLAR INSECT SCREEN

Super solar screening offers the ultimate in shading protection by blocking upto 90% of the sun’s heat. This vinyl coated fibreglass fabric also improves daytime privacy while offering excellent outward visibility. This screen works whether windows are open or closed. It keeps carpets and draperies from fading, as well as helps save energy.

POLYESTER TUFFSCREEN

It is heavy duty vinyl coated Polyester insect screening that is ideal for use in high traffic areas. Pet resistant and tear and puncture resistant. TuffScreen stronger than regular insect screening. It is excellent in use of pool, patio and porch enclosures as well as bigger doors.

BRONZE SCREEN

Bronze Screen is an effective way to control pests, while reviving the elegant charm of past years. Its Brite copper colour weathers to a beautiful dark bronze finish, co-ordinating with copper architectural accents such as roofing, dormers, and gutters. Made of 90% copper, it is excellent for use in screen doors, windows and porches providing strength and durability.

POOL & PATIO SCREEN

The traditional choice for patio and pool enclosures, the 18 x 14 Fiberglass Mesh Screening from Phifer are designed for applications where extra strength is desired. Built to withstand debris from harsh winds and storms, keep out most insects and other unwanted guests, but still allow for cooling breezes to flow through, these fibreglass screens make the perfect choice for any space that’s exposed to the more severe elements. Phifer’s Standard Pool & Patio insect screen is the traditional choice for patio and pool enclosures. Designed for applications where extra strength is desirable. Available in black.


Product Name

Product Description

Product Application

Alloy

Mesh Count

Colour

Sizes

Aluminium Brite Kote

Aluminium with transparent Coating

Traditional natural aluminium colour.
Durable Aluminium Finish.

5154A

18 x 16

Brite Kote

2ft - 5ft

Aluminium Charcoal

Aluminium with charcoal colour coating
(with electro deposition)

Charcoal finish reduces glare.
Good outward visibility. Weather resistant finish.

5154A

18 x 16

Charcoal

2ft - 5ft

Fiberglass

Fiberglass yarn with vinyl coating

Standard window & door mesh.
Good outward visibility. Will not rust, corrode & stain.
Flame retardant.

18 x 16

Silvergrey & Charcoal

3ft - 8ft

PetScreen

Polyester yarn with vinyl coating

Resists damage by pets. Heavy duty
insect screening. Seven times stronger than regular mesh

17 x 10

Black & Grey

3ft - 8ft

BetterVue

Fiberglass mesh with fine yarn with
better visibility

Durable. Flame retardant. Easy to fabricate
as standard fiberglass screen. Provides better curb
appeal than conventional screen.

20 x 20

Silvergrey & Charcoal

3ft - 6ft

SeeVue Stainless Steel

Stainless Steel with black powder
coating

Designed to maximize an outward view, making
it sharper and more brilliant. Excellent for porch
applications, visibility & outstanding durability.
Protects against harmful insects while allowing
exceptional air flow.

304

18 x 18

Black

3ft - 5ft

Bronze Screen

Bronze mesh

Provides strength & durability. Excellent choice
for inland & coastal regions. Weathers to a beautiful
dark bronze finish & Excellent outward visibility.

220

13 x 15

Golden

3ft - 5ft

TuffScreen

Polyester yarn with vinyl coating

Pet, tear and puncture resistant. Ideal for use in high
traffic areas, patios, porch enclosures, windows
& doors. Three times stronger than regular mesh.

17 x 13

Black

3ft - 11ft

Fiberglass Elite Mesh

Vinyl-coated fiberglass screen

Developed especially for Roller Screen & GREENGUARD
certified. Offers good ventilation and insect protection.

18 x 16

Silvergrey & Charcoal

4ft - 8ft

Pool & Patio Screen

Fiberglass yarn with vinyl coating

Excellent for large openings requiring extra strength.
Good outward visibility and air ventilation. This mesh
is called Pool, Porch & Patio mesh.

18 x 14

Charcoal

8ft - 11ft

Super Solar

Vinyl coated fiberglass

Blocks up to 90% sun’s heat & glare.
Good outward visibility. Mesh designed to cut sunlight
in addition to being an insect screen

17 x 13

Charcoal

3ft - 4ft
